Up to 3600W of Flexheat Undertile Heating Cable can be controlled by a single underfloor heating thermostat. For larger areas, please use multiple thermostats or a contactor to switch the load.
For warm floor application, use a thermostat with floor sensor only. For total heating, a thermostat should be used with both air and floor sensor, the exception to this would be wet areas, such as a bathroom where the thermostat must be mounted outside of the wet area with the floor sensor in the wet area floor.
FLEX•GRID Decoupling Membrane
A great underfloor heating solution for under tile requirements is to use a decoupling membrane suitable for use with electric under tile heating cable. Decoupling Membrane for Undertile Heating Cable:
- Material: Polyethylene (PE) film top; Polypropylene (PP) non-woven bottom.
- Weight: 1000g/sqm
- Thickness: 5.6mm
- Wire Cable Diameter: 3.6 - 4.2mm
- Distance of the studs: 4mm
- Waterproof: Yes
Available Roll Sizes:
1m x 1m
5m x 1m
10m x 1m
20m x 1m
The Flexheat Decoupling Membrane is a high-quality underfloor heating solution designed for use with electric under tile heating cable. Made of durable Polyethylene (PE) film on the top and Polypropylene (PP) non-woven fabric on the bottom, this decoupling membrane is both robust and long-lasting.
Weighing 1000g/sqm and with a thickness of 5.6mm, the Flexheat Decoupling Membrane provides a stable and secure base for your heating cable. It is suitable for use with heating cables with a diameter of 3.6 - 4.2mm, ensuring a snug fit and optimal heat distribution.
The membrane features studs spaced 4mm apart, providing the perfect spacing for your heating cable. This design allows for even heat distribution and efficient energy use, ensuring your floors are consistently warm and comfortable.
The Flexheat Decoupling Membrane is also waterproof, making it an excellent choice for areas with high moisture levels, such as bathrooms and kitchens. It protects your heating cable from moisture damage and ensures long-lasting performance.
Available in a range of roll sizes, including 1m x 1m, 5m x 1m, 10m x 1m, and 20m x 1m, the Flexheat Decoupling Membrane can be tailored to fit any project size. Upgrade your under tile heating system with this reliable and efficient heating solution.
Choice of Thermostats:
Manual Thermostat
The Adept Manual Dial Thermostat is an easy to use simple On/Off switch and an easy to adjust dial to choose your optimum temperature.
Features
- Easy to Use Dial Thermostat for Easy Temperature Control
- No complicated Setup Required
- On/Off Switch
IP Rating: IP20
Max Load: 16 amps
Supply Voltage: 230v
Programmable Thermostat
Provides precise control and is easily configured to control the temperature and timings for most heating systems, including Electric or Wet Underfloor Heating Systems.
Features
- Digital 7 Day Programmable or Non Programmable Thermostat
- Up to 4 Heating Periods Per Day
- Built In Sensor and Floor Sensor Included
IP Rating: IP21
Max Load: 16 amps
Supply Voltage: 230v
WiFi Thermostat
The Wifi Thermostat is a smartphone controllable stat perfect for use with underfloor heating systems or for use with electric heating devices or valve actuators. Wifi Thermostats allow you to use the included free app from your smartphone (available for both IOS and Android devices) to control the temperature of your heating device. The WiFi Thermostat gives you accurate and precise control anywhere in the home and is a premium choice for any household.
Features
- Smartphone Controllable via App
- Built In Sensor and Floor Sensor Included
- Control via Amazon Echo and Google Home Devices
IP Rating: IP21
Max Load 16 amps
The WiFi Thermostats only work on 2.4GHz WiFi
Order Before 1pm, Monday to Friday for Same Day Despatch
The delivery services we use are DPD, APC and Royal Mail depending on the size of the order. On large bulky orders we may use a pallet service to ensure your delivery gets to you safe and secure. If you have a preference on which delivery service you would like us to use please let us know.
*Standard Delivery - 2 to 3 Working Days
Free standard delivery is available on orders over £20 delivered to UK mainland.
Anything under £20 will have a £5.99 shipping cost
*Next Day Delivery Available
Spend over £100 to get free next day delivery to UK mainland.
Order before 1pm for same despatch. Our standard charge for next day delivery is £5.99 - Orders below £20 will have a £7.99 shipping cost.
*Saturday Delivery
We offer a Saturday delivery service on orders placed by 1pm on a Friday (excluding bank holidays) to UK mainland.
Please note that orders placed after 1pm will not be despatched on time for Saturday delivery. If you desperately require Saturday delivery feel free to contact us to see if we can help.
Free Collection from our Trade Counter
If you would like to collect your order from our trade counter please contact us to arrange this.
Our Address
Unit 16 Martlesham Creek Ind Est
Sandy Lane
Woodbridge
Suffolk
IP12 4SD
Opening Times
8am to 5pm, Monday to Friday (excluding bank holidays)
Manual Thermostat
The Adept Manual Dial Thermostat is an easy to use simple On/Off switch and an easy to adjust dial to choose your optimum temperature.
Features
- Easy to Use Dial Thermostat for Easy Temperature Control
- No complicated Setup Required
- On/Off Switch
IP Rating: IP20
Max Load: 16 amps
Supply Voltage: 230v
Programmable Thermostat
Provides precise control and is easily configured to control the temperature and timings for most heating systems, including Electric or Wet Underfloor Heating Systems.
Features
- Digital 7 Day Programmable or Non Programmable Thermostat
- Up to 4 Heating Periods Per Day
- Built In Sensor and Floor Sensor Included
IP Rating: IP21
Max Load: 16 amps
Supply Voltage: 230v
WiFi Thermostat
The Wifi Thermostat is a smartphone controllable stat perfect for use with underfloor heating systems or for use with electric heating devices or valve actuators. Wifi Thermostats allow you to use the included free app from your smartphone (available for both IOS and Android devices) to control the temperature of your heating device. The WiFi Thermostat gives you accurate and precise control anywhere in the home and is a premium choice for any household.
Features
- Smartphone Controllable via App
- Built In Sensor and Floor Sensor Included
- Control via Amazon Echo and Google Home Devices
IP Rating: IP21
Max Load 16 amps
The WiFi Thermostats only work on 2.4GHz WiFi
