Adept AD-RAIL In Screed Grip Rail Water Underfloor Heating Kits

Adept AD-RAIL In Screed Grip Rail Water Underfloor Heating Kits

Product Code:

The Adept AD-RAIL In Screed Grip Rail Water Underfloor Heating System is a complete kit suitable for Solid/Screed & Beam & Block.

Each kit comes with an A Rated Pump and WRAS approved 16mm PERT-AL-PERT pipe that will create a reliable and efficient Underfloor Heating solution.

Adept Inscreed Heating Kits are all designed for a single zone, however can be adjusted with the use of any Adept or Heatmiser controls from within our store. Each kit is designed to use 200mm centres using grip rails, with an output of 100W/m².


  Kit Size (m2):
20 40 60 80 100 120
Single Loop Control Pack: untitled-1.png
Manifold & Control Pack:   untitled-1.png untitled-1.png untitled-1.png untitled-1.png untitled-1.png
Manifold Ports:   2 3 4 5 6
Pipe Length (m): 100 200 300 400 500 600
Pipe Connectors: untitled-1.png untitled-1.png untitled-1.png untitled-1.png untitled-1.png untitled-1.png
Edge Insulation: 25 25 50 50 75 75
Pipe Clips: 200 400 600 800 1000 1200
Grip Rail: 20 40 60 80 100 120



  • Insulation should be rigid PIR.
  • Some insulation / screed combinations require a vapour barrier to be installed directly on the insulation before you install the pipe and lay the screed.
  • To comply with building regulations, you should use a minimum 65mm sand / cement screed or 50mm pumped screed.


Suitable Floor Constructions:
Solid / Screed
Suitable Floor Constructions:
Beam & Block
Suitable Floor Finishes:
Suitable Floor Finishes:
Suitable Floor Finishes:
Suitable Floor Finishes:
